As-Built Documentation of TOWARDEX owned utilities are published to allow our utility customers to plan for network construction, and to provide the public with the whereabouts of our facilities for locating and damage prevention.
State law requires that you call Dig Safe (811 or 888-344-7233) at least 72 hours prior to any excavation. When excavating in close proximity to existing utilities of any company, non-mechanical means shall be employed, as necessary, to avoid damage to underground plant (MGL c.82 § 40C ).
It is unlawful under the laws of the Commonwealth of Massachusetts for any person or corporation to enter upon the property of a utility company to affix or install wires for telecommunications, without first obtaining the consent of the owner of such property (MGL c.166 § 35 ). Unlawful and intentional act to injure, molest or destroy any line, wire, or any of the materials or property of a utility company is punishable by fine or imprisonment, or both (MGL c.166 § 38 ).
Route Planning
Keyhole Markup Language (KMZ) file for viewing the System Section on Google Earth. Please note that the exact positioning of assets in KMZ is not guaranteed to be accurate. Refer to individual As-Built sheet drawings to obtain accurate details of our facilities.
DOWNLOADAs-Built sheet of 700 Linear Feet (LF) section from 90 Inner Belt Road to 200 Inner Belt Road.
Interconnection with Joint Trench Partners (JTP) System also occurs in this section, between TWDX manhole C19BA-205 and Zayo manhole SOM10A.
VIEW DRAWINGAs-Built sheet of 70 Inner Belt Road at intersection with CoreSite South Driveway. Also covers C09B1 Joint Network Facilities - BSN South Lateral.
VIEW DRAWINGAs-Built sheet of 63, 65, 69 ‐ 70 Inner Belt Road.
VIEW DRAWINGAs-Built sheet of intersection between Inner Belt Road and Third Avenue.
To view connecting system on Third Avenue, go to C15A2 As Builts.
VIEW DRAWINGAs-Built sheet of 50 ‐ 59 Inner Belt Road to intersection with Third Avenue.
VIEW DRAWINGManhole Butterflies
Butterfly diagram for HEX manhole C19BA-205
VIEW DRAWINGButterfly diagram for HEX manhole C19BA-204
VIEW DRAWINGButterfly diagram for HEX manhole C19BA-203
VIEW DRAWINGButterfly diagram for HEX manhole C19BA-202
VIEW DRAWINGButterfly diagram for HEX manhole C19BA-201.
To view connecting system on Third Avenue, go to C15A2 As Builts.
VIEW DRAWING EAST WALLButterfly diagram for HEX manhole C19BA-200
VIEW DRAWINGDeeds and Siting Agreements
Easement Agreement between the City of Somerville ("Grantor") and TOWARDEX Technologies International, Inc. ("Grantee") regarding Hub Express System installations in Inner Belt. The Agreement covers City-owned streets in the area, which have not been statutorily adopted as Public Ways per MGL c.82 §§ 1-32.
